SPECIFICATIONS
Frame | M5 alloy | Style-Specific DH Geometry | horst pivot flip chip for 27.5 or 29 rear wheel | BSA threaded BB | full internal cable routing w/ option for full external brake | 148mm rear spacing | sealed cartridge bearing pivots | replaceable derailleur hanger | 200mm of travel |
---|---|
Fork | Öhlins DH38 M.1 29 | TTX Twin Tube Damping | external low speed rebound adjust | external high and low speed compression adjustment | 20x110mm | 58mm offset | 200mm of travel |
Shock | Öhlins TTX 22 M.2 Coil | external rebound adjust | external high and low speed compression adjustment | Trunnion mount | 225x75 |
Stem |
Renthal Integra 35mm Direct Mount Stem | 45mm length |
Handlebar |
Renthal Fatbar 35 | 5-degree upsweep | 7-degree backsweep | 30mm rise | 800mm | 35.0mm |
Grips | Deity Lockjaw |
Brakes | F: SRAM Maven Ultimate | 4-piston caliper | hydraulic disc | 220mm R: SRAM Maven Ultimate | 4-piston caliper | hydraulic disc | 200mm |
Shifters | SRAM X01 DH | trigger | 7-speed |
Rear derailleur | SRAM X01 DH | 7-speed | trigger |
Cranks & chainrings |
SRAM X01 DH | DUB | carbon | Direct mount ring | 165mm | 34T |
Bottom Bracket |
SRAM DUB 83mm |
Cassette | SRAM X01 DH 7-speed | 10-24t |
Chain | SRAM PC1130 w/ Powerlink 11-speed |
Front Hub
|
DT Swiss 350 hub | 20x110mm |
Rear Hub |
DT Swiss 350 hub | 12x148mm |
Spokes | Sapim D-Light |
Rims | Roval Traverse Alloy 29" / 27.5" | 32h alloy rim | 28mm inner rim width |
Tires | F: Cannibal | GRID GRAVITY casing | GRIPTON T9 compound | 2Bliss Ready | 29x2.3" R: Cannibal | GRID GRAVITY casing | GRIPTON T9 compound | 2Bliss Ready | 27.5x2.3" |
Seatpost |
Thomson alloy | straight | 12-degree clamp |
Saddle |
Body Geometry Henge DH | hollow titanium rails | 130mm |
Color | Gloss Obsidian / Brushed / Chameleon Supernova |
Weight | 17.62 kg (38.84 lbs) | size S3 |
