Features |
The perfectly balanced advantage
It’s light. It’s stiff. It climbs. It does everything you expect a good cross country bike to do. But then, its subtly aggressive geometry and lengthened wheelbase changes the game when descending and charging fast, rough, technical sections of singletrack.
Lightweight trail dominance
With 130mm of smooth, progressive travel, the Element is in a totally different league than every cross country bike that came before it. Progressive geometry means you can not only ride more trails up and down than ever—they’re now faster, too.
The comfort of confidence
Soaking up aggressive sections of trail means more matches to burn as the day goes on. Ride further than ever in surprising levels of comfort. Keep cottonmouth at bay with plenty of room to carry two full-sized bottles. Ride more trails than ever—and do it comfortably.
|
---|---|
Technology |
SMOOTHWALL™ Carbon
Smoothwall carbon uses one of the world’s most sophisticated carbon processes to deliver industry leading stiffness-to-weight, ride quality, and durability.
RIDE-4™ adjustment system
The RIDE-4 adjustment system allows riders to quickly fine-tune their geometry with a pair of Allen keys. Four configurations are possible thanks to one rotating chip.
SMOOTHLINK™ suspension
Smoothlink suspension is efficient yet supple when you’re on the pedals and across a wide range of gears. It features a controlled end-stroke and a rate-curve that feels more capable than the travel would suggest.
Bottle clearance and mount options The lower bottle mounts have two positions, giving you the option to mount the lower bottle closer or further from your hand depending on your chosen configuration. |
Frame |
SMOOTHWALL™ Carbon | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | RIDE-4™ Adjustable Geometry + Suspension Rate | 120mm Travel. SMOOTHWALL™ Carbon Rear Triangle
|
---|---|
Fork |
Fox 34 Float Performance 130mm | 44mm Offset
Front travel: 130mm
|
Shock |
Fox Float DPS Performance | Sealed Bearing Eyelet | 20x8mm F Hardware | All Sizes = 190x45mm
Rear travel: 120mm
|
Headset |
FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race
|
Stem |
Rocky Mountain 31.8 XC | 5° Rise | All Sizes = 50m
|
Handlebar |
Rocky Mountain AM | XS = 760mm | SM - XL = 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp
|
Grips |
ODI Elite Pro Lock On
|
Brakes | Shimano SLX 2 Piston | Resin Pads | F:Shimano RT64 180mm | R:Shimano RT64 180mm |
Shifters |
Shimano XT
|
Rear derailleur |
Shimano XT
|
Cranks & chainrings |
Race Face Aeffect Cinch | 32T Steel | 24mm Spindle | Crankarm Length: XS = 165mm Crankarm | SM - XL = 170mm
|
Bottom Bracket |
Shimano SM-BBMT500
|
Cassette |
Shimano SLX 10-51T
|
Chain | Shimano M7100 |
Front Hub
|
Rocky Mountain Sealed Boost 15mm
|
Rear Hub |
DT Swiss 370 Boost 148mm | 18T Star-Ratchet
|
Spokes |
DT Swiss Competition 2.0/1.8/2.0
|
Rims |
WTB ST Light i27 TCS 2.0 Tubeless | 28H | Tubeless Ready - Tape / Valves Incl
|
Tires |
F: Maxxis Rekon 2.4 WT EXO Tubeless Ready
R: Maxxis Rekon 2.4 WT EXO Tubeless Ready
|
Seatpost |
Rocky Mountain Toonie Drop Composite 30.9mm | XS - SM = 125mm | MD = 150mm | LG - XL = 170mm
|
Saddle |
WTB Silverado Race 142
|
Color |
Green/Blue
|
App. weight |
N/A
|
