FEATURES
SPECIFICATIONS
Frame | FACT 11m carbon chassis and rear-end | Trail Geometry | SWAT Door integration | head tube angle adjustment | threaded BB | internal brake and dropper cable routing | 12x148mm dropouts | sealed cartridge bearing pivots | SRAM UDH compatible | 145mm of travel |
---|---|
Fork |
FOX FLOAT 36 Rhythm | GRIP damper | two-position Sweep adjustment | 15x110mm QR axle | 44mm offset | S1:140mm of travel | S2-S6:150mm of travel
|
Shock | FOX FLOAT Performance w/ Specialized GENIE Shock Tech | Ride Dynamics Trail Tune | 2-position lever w/ LSR adjustment | S1:210x52.5mm | S2-S6:210x55mm |
Stem | Alloy Trail Stem | 35mm bar bore |
Handlebar | Specialized 6000 series alloy | 6° upsweep | 8° backsweep | S1-S2: 780 width, 20mm rise | S3-S4: 800 width, 30mm rise | S5-S6: 800 width, 40mm rise |
Grips | Specialized Trail Grips |
Brakes | F: SRAM Maven Bronze | 4-piston caliper | hydraulic disc | 200mm HS2 Rotor R: SRAM Maven Bronze | 4-piston caliper | hydraulic disc | S1-S2: 180mm | S3-S6: 200mm HS2 Rotor |
Shifters | SRAM AXS POD Controller |
Rear derailleur | SRAM S1000 Eagle Transmission Derailleur |
Cranks & chainrings |
SRAM S1000 Crankset | 32T ring | Integrated Guard | 55mm Chainline | S1-S3:165mm | S4-S6: 170mm
|
Bottom Bracket |
SRAM DUB | BSA 73mm Wide | Threaded
|
Cassette | SRAM XS-1270 Transmission Cassette | 12spd | 10-52t |
Chain | SRAM GX Eagle Transmission Flattop Chain |
Front Hub
|
Alloy | sealed cartridge bearings | 15x110mm thru-axle | 28h |
Rear Hub |
Alloy | sealed cartridge bearings | 12x148mm thru-axle | 28h
|
Spokes | DT Swiss Industry |
Rims | Specialized | hookless alloy | 30mm inner width | tubeless ready | Front: 29, Rear: S1-S2:27.5, S3- S6:29 |
Tires | F: Butcher | GRID TRAIL casing | GRIPTON T9 compound | 2Bliss Ready | 29x2.3" R: Eliminator | GRID TRAIL casing | GRIPTON T7 compound | 2Bliss Ready | S1-S2: 27.5x2.3 | S3- S6: 29x2.3" |
Seatpost | X-Fusion Manic | infinite adjustable | two-bolt head | bottom mount cable routing | remote SLR LE lever | 34.9mm | S1: 125mm | S2: 150mm | S3: 170mm | S4-S6: 190mm |
Saddle | Bridge Comp | Hollow Cr-mo rails | S1-S2: 155mm | S3-S6: 143mm |
Color | Satin Burnt Gold / Gunmetal |
Weight | 14.87 kg | 32.8 lbs (size S4) |
