It starts with Specialized's Turbo Full Power 2.2 motor and Master Mind Turbo Connect Unit (TCU), which provide Levo with a smooth and seamless amplification of your efforts—4x your power that lets you choose where to ride, and when you want to do it. Levo also shatters limitations when it comes to range, amplifying your effort for up to five hours of trail time. Now you can ride farther, and explore more, than ever before. And the optimized chassis boasts 150mm of custom-tuned rear suspension and adjustable geometry that delivers a stable and natural ride like no other. Because at the end of the day, it’s the ride that matters.
Spec’d with a no-fuss SRAM NX/GX drivetrain, trail-taming Marzocchi suspension, and a lightweight, durable alloy wheelset, the Turbo Levo delivers more of everything that you love about trail riding.
FEATURES
Motor | Specialized Turbo Full Power System 2.2 Motor 90Nm Torque | 565W Power |
Battery | Specialized M3-700 | Integrated battery | 700Wh |
UI/Remote | Specialized MasterMind TCU | percentage of remaining charge | 120 possible display configurations | MicroTune assist adjustment | ANT+/Bluetooth | w/Handlebar remote |
---|---|
Charger | Custom charger | 42V4A System w/ Rosenberg Plug | 100-240V |
Wiring Harness | Custom Specialized wiring harness |
Frame | Specialized M5 premium alloy | BB height adjust | S-Sizing | internal cable routing | 150mm travel | 148mm spacing |
---|---|
Fork |
Marzocchi Bomber Z1 29" | S2-S6: 160mm | S1: 150mm | sweep adjust compression |
Rear Shock |
Marzocchi Bomber inline | S2-6: 210x55mm | S1: 210x52.5 | low speed rebound adjust |
Stem | Alloy Trail Stem | 35mm bar bore |
Handlebar |
6061 mtn bars | 35mm diameter | 8 degree back sweep | 6 degrees up sweep | 800mm width | S1/S2: 30mm rise | S3-S6: 40mm rise |
Grips | Specialized Trail Grips |
Brakes |
F: SRAM DB | 220mm rotor
R: SRAM DB8 | 200mm rotor
|
Shifters | SRAM NX Eagle | single-click lever |
Rear derailleur | SRAM GX Eagle 12-speed |
Cranks & chainrings |
Praxis Forged M30 | 160mm custom offset
SRAM X-Sync Eagle | 104 BCD | 32T | steel
|
Cassette | SRAM NX Eagle 12-speed | 11-50t |
Chain | SRAM NX Eagle 12-speed |
Rims |
Specialized 29 | hookless alloy | 30mm inner width | tubeless ready |
Front hub | Alloy | sealed cartridge bearings | 15x110mm thru-axle | 28h |
Rear hub |
Alloy | sealed cartridge bearings | 148mmx12mm thru-axle | 28h |
Spokes |
DT Swiss Industry |
Tires |
F: Butcher | GRID TRAIL casing | GRIPTON T9 compound | 2Bliss Ready | 29x2.3" R: Eliminator | GRID GRAVITY casing | GRIPTON T9/T7 compound | 2Bliss Ready | 27.5x2.3" |
Seatpost | TranzX dropper | 34.9mm | S1: 100mm | S2: 125mm | S3: 150mm | S4-S5: 170mm | S6- 200mm |
Saddle |
Body Geometry Bridge Saddle | steel rails |
Accessories | SWAT CC steerer tube integrated tool with chain tool and link |
Color |
Black / Light Silver / Black |
Weight | 24.21 kg (53.37 lbs) | size S4 |
