RC Tune: Full Torque and Balanced Power
Rider Synergy (RS Gen2) is central to Denna'a go-anywhere capabilities. Weight, power and simplicity plus a best-in-class battery range means you can rewrite your idea of what is possible.
50C Tire Clearance
Denna has clearance for up to 50C tires, so you can even fit many mountain bike tires for maximum grip and comfort.
420 Wh Battery
Our 420 Wh battery offers more power in a lighter, smaller package. Thanks to the energy savings from our RD Gen2 RC firmware, the average rider will get up to 3500m of climbing from this battery.
Frame Absorption Points
Specifically shaping the frame at key points allows controlled vertical flex bumps and chatter coming from rougher paths. The tube shape here resist lateral flex, meaning we don't compromise Denna's pedaling efficiency or handling.
Motor | Shimano EP801 |
Battery |
Orbea Internal 420Wh |
---|---|
Charger |
Orbea 2.Generation eBike Smart charger 42V/2-4A |
Remote | EN600-L |
Frame |
Orbea Denna | Thru Axle 12mm x 142mm rear | thread M12xP1 | internal cable routing |
---|---|
Fork |
Orbea Denna OMR ICR full carbon | 1-1/8" - 1,5" | tapered head tube compatible | Thru axle 12x100mm | thread M12xP1 |
Steerer Tube |
FSA 1-1/2" Integrated Aluminium Cup |
Stem |
OC Road Performance RP22 | -5º |
Handlebar |
OC Gravel GR31 | Reach 70 | Drop 110 |
Tape | Orbea Anti-Slippery/Shock Proof |
Brakes | Shimano RX400 Hydraulic disc |
Shifters | Shimano GRX RX822 GS |
Rear derailleur | SRAM Eagle 90 T-Type |
Cranks & chainrings | Shimano Steps EM600 Alloy EP8 42t |
Cassette | Shimano CS-M7100 10-45t 12-Speed |
Chain |
Shimano M6100 |
Wheels | Oquo Road Control RC25PRO |
Front axle | Orbea Thru Axle 12x100mm M12xP1 Hollow |
Rear axle | Orbea Thru Axle 12x142mm M12xP1 Solid inner threaded |
Tires | Vittoria Terreno Dry Gravel G2.0 TLR 700x45c |
Seatpost | OC Performance XP10 Carbon | 27.2mm | Setback 0 |
Saddle | Bridge Comp | Hollow Cr-mo rails | 155/143mm |
Color | Gloss Green/Foggy Matt |
Weight | N/A |
